| Place of Origin: | Jiangsu, China (Mainland) |
| Brand Name: | Dyun |
| Certification: | CE&ISO |
| Minimum Order Quantity: | 1 - 1 Pieces |
|---|---|
| Price: | Negotiable |
| Condition: | New | Application: | Granules |
|---|---|---|---|
| Plastic Processed: | Pp,pet,pvc,ps,pc,abs,pmma | Screw Design: | Single-screw |
| Automatic Grade: | PLC | Voltage: | 380V |
| Power(W): | 15-37kw | Dimension(L*W*H): | 1.5mX1.5mX3m |
| Weight: | 2-4ton | After-sales Service Provided: | Field Installation, Commissioning And Training |
| Warranty: | 1 Year | Color: | Customerised |
| Port: | Shanghai | ||
| High Light: | waste plastic crusher,plastic shredder machine |
||
Waste tyre recycling production line is composed of several kinds of heavy equipment, waste tyre recycling crushing processing equipment DYUN can provide. The pretreatment of the tire USES the large biaxial shredding machine, automobile tires, directly after shredding tires by conveyor to the sieving machine for material screening, screening of conveying to the next level after mill for further refining processing. According to customer requirements,the material of rubber for further dicing, separation of steel wire and fiber processing.
|
Specification of DYSS Double Shaft Shredder
|
||||||
|
MODEL
|
ROTOR BLADE QUANTITY (PIS)
|
DRIVE POWER
(KW) |
THICKNESS OF BLADES (MM)
|
CRUSH CHAMBER SIZE MAX.
|
ROTOR BLADE SWING DIAMETER
(MM) |
ROTOR SPEED (RPM)
|
|
DYTSS-1980
|
42
|
2*11
|
18.5
|
480*800
|
Ф245
|
16-25
|
|
DYTSS-2380
|
32
|
22
|
25
|
600*800
|
Ф290
|
16-25
|
|
DYTSS-33100
|
20
|
2*30
|
50
|
830*1000
|
Ф430
|
10-15
|
|
DYTSS-41140
|
28
|
2*37
|
50
|
1050*1400
|
Ф534
|
10-15
|
|
DYTSS-41160
|
32
|
2*45
|
50
|
1050*1000
|
Ф534
|
10-15
|
|
DYTSS-501300
|
32
|
2*55
|
50
|
1200*1300
|
Ф650
|
10-15
|
The pretreatment of the tire USES the large biaxial shredding machine, automobile tires, directly after shredding tires by conveyor to the sieving machine for material screening, screening of conveying to the next level after mill for further refining processing. According to customer requirements,the material of rubber for further dicing, separation of steel wire and fiber processing.
