    Product Details:

    Place of Origin: Jiangsu, China (Mainland)
    Brand Name: Jwell
    Certification: CE ISO SGS

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 - 4 Sets
    Price: Negotiable
    Packaging Details: Wooden package forJwell HDPE Water Supply Pipe/Gas Pipe Energy-saving and high speed Extruded Plastic Profiles.
    Supply Ability: 20 Set/Sets per Month Jwell HDPE Water Supply Pipe/Gas Pipe Energy-saving and high sp
    Contact Now
    Detailed Product Description
    Condition: New Application: Pipe
    Plastic Processed: PE Screw Design: Single-screw
    Automatic Grade: Fully Automatic Voltage: Customized
    Power(W): 55kw Dimension(L*W*H): 4200*1500*2100
    Weight: 4000kg Type: PE63
    Extruder: 65/33 Capacity: 120-150kg/h
    Length Of Production Line: 30m Speed: 1.2-12m
    Power: 104kw Motor Power: 45kw
    Mould Power: 11kw Pressure Degree: SDR11/SDR17
    Name: Jwell Gas Pipe Energy-saving And High Speed Extruded Plastic Profiles After-sales Service Provided: Engineers Available To Service Machinery Overseas
    Port: Shanghai
    High Light:

    pvc pipe production line

    ,

    plastic pipe production line

    Jwell  HDPE Water Supply Pipe/Gas Pipe Energy-saving and high speed Extruded Plastic Profiles

    Product Description

    Features & Advantages: The Large Diameter HDPE/MDPE Pipe Extrusion Line research & developed by Jwell Machinery Co., features of unique structure, easily control, highly automation and stable performance. Pipes produced by this machine has the moderate rigidity, strength, as well as good flexibility, anti-rot, anti-stress split, and favorable hot melting, make this large diameter pipe considered as the prefer product for water and gas transportation system in cities.

     Jwell HDPE Water Supply Pipe/Gas Pipe Energy-saving and high speed Extruded Plastic Profiles 0



    Main Technical Parameter:



    DiameterExtruderCapacityPower
    450-800120/33 or 150/331000-1300600
    630-1000150/331000-1300630
    800-120090/33;120/33 or 150/331000-1500900
    1000-1600120/33 or 150/331000-17001300
    1400-2300120/33;120/33 or 150/331500-20001400
    2000-3000120/33;120/33 or 150/332000-25001550








    Note:The specifications are subject to change without prior notice.



    The modern developed 2-layer or 3-layer spiral mould is specially for double-anti pipe extrusion. This pipe owns even and equal co-extrusion wall thickness, the inner and outer wall made of double-anti material (Anti-flammable, anti static electricity), the core layer of HDPE wall, reasonably reduce the costs of double-anti material, accordingly reduced the costs of the whole product.





    HDPE Water Supply Pipe, Gas Pipe Energy-saving and High Speed Extrusion Line

    This production line adopts the most advanced technology of Europe,it is a new research achievement of energy-saving production line,which is suitable for high speed extrusion of HDPE,PP and other polyolefin pipe.compared with common production line,the energy-saving effect reach on 35%, and the product efficiency increase more than 1 times, thus it is not only saving the cost of site and manpower,but also improving efficiency.This production line has nice appearance,higher automatical degree ,production reliable and stable.

    Jwell HDPE Water Supply Pipe/Gas Pipe Energy-saving and high speed Extruded Plastic Profiles 1

    Main Technical Parameter:



    DiameterExtruderCapacityPower
    20-7550/38320kg/h150kw
    50-25075/38550kg/h230kw
    160-45090/38850kg/h450kw
    315-630120/381200kg/h630kw
    450-800120/381200kg/h680kw
    800-1000150/381400kg/h815kw
    710-1200150/381400kg/h930kw
    900-1600150/38;75/381900kg/h1200kw
    1200-2000150/38;90/382200kg/h1400kw
    1600-2500150/38;120/382500kg/h1580kw
    2000-3000150/38;120/382500kg/h1580kw






    Common Diameter HDPE Pipe , PP Chemical Usage Pipe and MPP Electrical Wire Protection Pipe Extrusion Line

    Advantage:Our company using the development HDPE,PP pipes extrusion technology develops this kind of extrusion line. This line features compact structure, highly automation and stable performance. This line is widely used in producing HDPE water, gas supply pipe, double-anti pipe for mine industries.

    Jwell HDPE Water Supply Pipe/Gas Pipe Energy-saving and high speed Extruded Plastic Profiles 2



    Main technical parameters:

    TypeDiameterExtruderOutput capacity(kg/h)Power(kw)
    JWPEG6320-63MM25/25;65/33 120-150 110
    JWPEG16063-160MM25/25;65/33 120-300 160
    JWPEG25075-250MM25/25;75/33 280-400 210
    JWPEG450160-450MM25/25;90/33 500-700 385
    JWPEG630315-630MM25/25;120/33 700-900 535



    Product Picture:
     Jwell HDPE Water Supply Pipe/Gas Pipe Energy-saving and high speed Extruded Plastic Profiles 3

    Product Accessories:
    Jwell HDPE Water Supply Pipe/Gas Pipe Energy-saving and high speed Extruded Plastic Profiles 4

    Extruder

    Name: 63 single screw extruder

    Brand:Jwell

    Screw: Jin Hailuo

    Type:65/33

    Capacity:120-150kg/h



    Electrical parts

    Power: 45kw
    Motor: Siemens
    Control Panel: Simens PLC
    Electrical Spareparts: Schneider

    Frequency convertor: ABB

    Jwell HDPE Water Supply Pipe/Gas Pipe Energy-saving and high speed Extruded Plastic Profiles 5
    Jwell HDPE Water Supply Pipe/Gas Pipe Energy-saving and high speed Extruded Plastic Profiles 6

    Haul-off Unit

    Haul-off method: rubber block caterpillar.

    Haul-off motor:4KW x 2 sets

    Press method:pneumatic pressing
    Number of caterpillars: 2sets;

    Driving Motor: 1.5kw*2

    Length of caterpillar:1400mm


    YFD1000 Vacuum calibration table

    Calibration tanks and basin are made of stainless steel
    Table length: 5800mm.
    Stroke: 500mm
    Vacuum pump: 3KW x 2set
    Vacuum degree:0 -0.09 Mpa
    Water pump: 3kwx2

    Cooling method: Spraying

     Jwell HDPE Water Supply Pipe/Gas Pipe Energy-saving and high speed Extruded Plastic Profiles 7




    Packaging & Shipping

     Packaging & Shipping:

    • Wooden package for Jwell plastic profile sheet extrusion machine for PVC.
    • Jwell produces more than 2000 sets of extrusion machines each year, which has been sold to all over the world, including America, Brazil, Japan, Korea, India, Germany, Turnkey, Malaysia.etc.

    Jwell HDPE Water Supply Pipe/Gas Pipe Energy-saving and high speed Extruded Plastic Profiles 8



    Company Information

    Brief Infomation of JWELL MACHINERY CO., LTD

    • The largest plastic extrusion manufacturer in China with 18 professional subsidiaries, 9 big metal-working workshops and 4 big heat-treatment nitration workshops.
    • Founded in Shanghai, China 1997,has developed into 5 production bases including Shanghai, Suzhou, Changzhou, Zhoushan and Guangzhou with more than 1000mu area.
    • JWELL MACHINERY (CHANGZHOU) CO., LTD. is another development strategy center of Shanghai JWELL Machinery Co.,ltd, locating at Jiangsu Zhongguan cun technology industrial park, Liyang city, Jiangsu province.
    • We have a high qualified R&D and experienced mechanical and electrical engineer team as well as advanced processing foundation and normative assembly shop.
    Jwell Culture:
    • Jwell Enterprise Spirit: Attentive,Edurung,Quick and Orderly;
    • Jwell Quality Orientation:Excellent performance, Perfect Products;
    • Core Idea:Be honest to people,Be faithful to Jwell.
    Jwell HDPE Water Supply Pipe/Gas Pipe Energy-saving and high speed Extruded Plastic Profiles 9

    Changzhou Jwell Machinery Co.,Ltd is another development strategy center of Shanghai Jwell Machinery Co.,ltd,located at Jiangsu zhongguancun Technology Industrial Park, Liyang city, Jiangsu province, a high-tech manufacturer specializing in R&D of plastic extrusion equipment. The factory area is about 400 acres; we have a high qualified R&D and experienced mechanical and electrical engineer team as well as advanced processing foundation and normative assembly workshop. Our enterprise spirit is :Attentive, Enduring, Quick and Orderly. Welcome both new and old customer to visit us for investigation, guidance and cooperation. Welcome to Changzhou, welcome to Jwell!

    Jwell HDPE Water Supply Pipe/Gas Pipe Energy-saving and high speed Extruded Plastic Profiles 10


    Jwell HDPE Water Supply Pipe/Gas Pipe Energy-saving and high speed Extruded Plastic Profiles 11

     Jwell HDPE Water Supply Pipe/Gas Pipe Energy-saving and high speed Extruded Plastic Profiles 12

    Our Services

    All to start and keep good & long-term cooperation with you.

    • We are the largest plastic extrusion manufacturer in China with 18 professional subsidiaries, 9 big metal-working workshops and 4 big heat-treatment nitration workshops.
    • Production capacity:20 set/sets per Month.
    • We  can provide on-site installation and debugging services freely, including operation train and raw material formula , to insure the customer can operate autonomously.
    • Warranty:12 months.

    Jwell HDPE Water Supply Pipe/Gas Pipe Energy-saving and high speed Extruded Plastic Profiles 13

    Certifications:

    Jwell HDPE Water Supply Pipe/Gas Pipe Energy-saving and high speed Extruded Plastic Profiles 14



    FAQ

    Q1--How much does it cost?

         --Please fill in your specific requirement in the bottom blank and sent to us, so that we could make a detail quotation for you.



    Q2:--I want to know more about your company and your products, how?

          --For more information, please visit our website: www.jwell.cn or www.jwellcz.cn. The best way, of course, is to go to our factory and see our products. Jwell welcomes your coming at any time!



    Q3:-- How about your after-sale service?

         --When the machines are ready and be sent to your factory, we will sent our engineers to your factory to help your worker to do the installation and train your workers. Above all, we have the maintenance engineers all over the world, who are always ready to go to our customer's factory and provide them with the best after-sale service



    Q4:--Where is your factory located?

         --We are in No.118, Shangshang Road, Liyang, Changzhou city, Jiangsu province. welcome to visit us!!!
